Oshkosh Defense® TAK-4® Family of Independent Suspension Systems

There are no compromises. And absolutely no comparisons.

Scale a rocky slope. Outmaneuver the enemy. Haul equipment with capacity to spare. Nothing should stand in the way of the mission. The Oshkosh® TAK-4® family of independent suspensions gives any vehicle – from light tactical trucks to heavy equipment transporters – the protection, mobility and payload capacity to effectively complete demanding missions.

Our experts leverage decades of ground operations experience and unmatched vehicle knowledge to design and deliver superior suspension systems. We understand what it takes to protect crews, achieve higher speeds, haul the heaviest loads and overcome harsh terrain. Over and over, TAK-4 suspensions deliver scalable solutions to improve ride quality, protection and mobility.



» Performance Over and Above All Obstacles Ahead

  • S-CAM or wedge drum brakes
  • Standard coil spring option
  • Hydro-pneumatic spring option
  • High-pressure gas (HPG) spring option
  • Up to 16 in. (40.6 cm) independent wheel travel

» Next-generation Technology that Sets a New Standard for Off-road Mobility

  • Disc brakes & HPG springs
  • Up to 20 in. (50.8 cm) independent vertical wheel travel
  • Self-leveling SAES
  • Raise & lower using interior controls

» The Proven, Reliable Suspension Solution for HMMWV

  • Integrated onto HMMWV
  • High-performance disc brakes
  • High-performance coil springs
  • 14 in. (35.5 cm) of independent wheel travel
Independent Suspension System


Featured on the M-ATV, LVSR, PLS A1, P-19R and MTVR platforms, the TAK-4 independent suspension system steadily thunders over whatever comes its way. Equipped with this suspension, the Oshkosh® MRAP All-Terrain Vehicle (M-ATV) quickly proved to be lighter with greater maneuverability and ride quality, while maintaining MRAP-level protection against threats. First used on the U.S. Marine Corps Medium Tactical Vehicle Replacement (MTVR), the Oshkosh TAK-4 family of independent suspension systems sets Oshkosh apart as the leader in off-road military mobility and has been applied to more than 25,000 tactical wheeled vehicles.

Intelligent Independent Suspension System


Take harsh terrain head on with TAK-4i™ intelligent independent suspension*. This suspension has demonstrated its capabilities on the Oshkosh® JLTV, delivering next-generation mobility that outmaneuvers, outlasts and out performs any other suspension. It delivers superior ride quality to achieve higher speeds across rougher terrain. Designed with state-of-the-art technologies and a full 20 inches (50.8 cm) of usable wheel travel and a self-leveling Suspension Aided Egress System (SAES) on longitudinal or lateral slopes when parked, TAK-4is a scalable solution for unprecedented mobility and safety for any tactical wheeled vehicle.

*Patent pending

Light Independent Suspension System


TAK-4l™ independent suspension* takes the most rugged, reliable suspension system and applies it to light vehicle platforms. Designed to enhance the mission capabilities of the HMMWV, TAK-4l is an integrated driveline solution that allows light vehicles to maintain full payload capacity, while improving suspension travel and overall ride quality. The result: A higher level of mobility, versatility and survivability for a variety of light vehicle missions.

*Patent pending
